Det-tronics Fire and Gas Detection Systems

tek-gozlu-alev-dedektoru500x500

Det-tronics Ex-Proof Flame Detectors

gaz-algılama-sistemleri-det-tronics500x500

Det-tronics Gaz Detectors

EQP security systems can be flexibly configured with flame and gas detector detection, alarm information and warning, gaseous and predominant valve solutions.

In dangerous areas; The Eagle Quantum Premier (EQP) safety system is a system that can perform monitoring and protection functions of the extinguishing system and: fire and gas detection at the same time.

FUNCTIONAL;

– FM approved to ANSI/NFPA-72-2010 National Fire Alarm Code
– Compliance to ANSI/ISA-12.12.01-2000 electrical equipment performance standard
– Performance certified to FM 6310/6320 for gas detection
– SIL 2 Capable certification
– Performance approved to ATEX EN60079-29-1, and CSA 22.2 No. 154 for gas detection
– EN54 compliant
– USCG, Lloyd’s Register type approval for offshore
– Explosion-Proof for Class I Division 2 Groups A, B, C, D (T4) and Class I Zone 2

FLEXIBLE;

– Modbus TCP/IP Master/Slave; Modbus RTU Master/Slave, and Allen Bradley ControlNet™ – communication capability
– Emerson AMS Suite integration through S3
– Compatible with Det-Tronics flame and gas products
– Accommodates a variety of third-party devices with 4-20 mA or “dry contact” type inputs
– Execute fire and gas alarm and suppression control
– Programmable logic
– 246 or 16 node capacity

RELIABLE;

– Up to 246 addressable field devices and 32,500 feet (10,000 meters) of wiring on the network
– Deluge/agent and pre-action release capability for fire suppression
– Simplex or redundant operation
– Extensive built in diagnostics

Safety System Software (S3)

An industrial facility says “Danger is coming!” with alarms. Proper and serious programming is required to transfer this to the operator. Otherwise, the risk you take will be higher than the investment you make. The S3 program offers a unique solution to achieve a sustainable competitive advantage and to facilitate today’s programming processes. Here are a few of the advantages it provides.

It can perform the following functions via serial or ethernet port.

– Configurations of field devices
– User program
– User logic creation (IEC61131-3)
– User simulation and test support
– Online logical monitoring
– Drawing of the logic
– Point display in the configuration
– Modbus and Allen Bradley connection
– Logic editor enhancements

S3 software is fully compatible with Det-Tronics products and third-party devices with the Eagle Quantum network. The S3 graphics program is highly suitable for gas detection, fire detection and fire extinguishing.

To ensure easy communication with existing systems, S3 distributed control systems can provide data safely with other OPC compatible devices. It is compatible with Emerson AMS Suite.
